Aluminum Honeycomb Core Shipped In Strip Form For Sandwich Panels
1. Descriptions:
Aluminum honeycomb core can be delivered in many forms, such as aluminum honeycomb core block, aluminum honeycomb core strip, unfolding aluminum honeycomb core, and different packaging can be carried out according to the requirements of customers.
Aluminum honeycomb core is made of aluminum foil which processed through gluing, stacking, hot pressing, sawing, and then stretched to regular hexagon. It has the advantages of regular hexagon shape, good mechanical properties, flat surface etc.
Application: Clean-room system, railway transportation, construction and decoration, electrical appliance, solar thermal utilization and new energy vehicle.
2. Aluminum honeycomb core structure:
3. Aluminum honeycomb core pecifications:
| Micro-Porous Aluminum Honeycomb Core |
| Specifications | Side length (mm) | Foil Thickness (mm) | Density (kg/m³) |
| BHC3003-0.4-0.015L | 0.4 | 0.015 | 137 |
| BHC3003-0.5-0.015L | 0.5 | 0.015 | 137 |
| BHC3003-0.5-0.021L | 0.021 | 190 |
| BHC3003-0.6-0.015L | 0.6 | 0.015 | 151 |
| BHC3003-0.6-0.021L | 0.021 | 158 |
| BHC3003-0.8-0.021L | 0.8 | 0.021 | 118 |
| BHC3003-0.8-0.025L | 0.025 | 144 |
| BHC3003-0.8-0.03L | 0.03 | 169 |
| BHC3003-1-0.025L | 1 | 0.025 | 115 |
| BHC3003-1-0.03L | 0.03 | 137 |
| BHC3003-1-0.04L | 0.04 | 183 |
| BHC3003-1.5-0.03L | 1.5 | 0.03 | 90 |
| BHC3003-1.5-0.04L | 0.04 | 122 |
| BHC3003-1.5-0.05L | 0.05 | 152 |
| BHC3003-1.83-0.04L | 1.83 | 0.04 | 99 |
| BHC3003-1.83-0.05L | 0.05 | 123 |
| BHC3003-1.83-0.06L | 0.06 | 148 |
| BHC3003-2-0.04L | 2 | 0.04 | 90 |
| BHC3003-2-0.05L | 0.05 | 113 |
| BHC3003-2-0.06L | 0.06 | 135 |
| BHC3003-2.5-0.04L | 2.5 | 0.04 | 74 |
| BHC3003-2.5-0.05L | 0.05 | 92 |
| BHC3003-2.5-0.06L | 0.06 | 110 |
| BHC3003-3-0.04L | 3 | 0.04 | 61 |
| BHC3003-3-0.05L | 0.05 | 76 |
| BHC3003-3-0.06L | 0.06 | 91 |
| BHC3003-3-0.08L | 0.08 | 122 |
| BHC3003-3.5-0.04L | 3.5 | 0.04 | 55 |
| BHC3003-3.5-0.05L | 0.05 | 68 |
| BHC3003-3.5-0.06L | 0.06 | 82 |
| BHC3003-3.5-0.08L | 0.08 | 110 |
| BHC3003-4-0.04L | 4 | 0.04 | 46 |
| BHC3003-4-0.05L | 0.05 | 57 |
| BHC3003-4-0.06L | 0.06 | 68 |
| BHC3003-4-0.08L | 0.08 | 92 |
| BHC3003-5-0.05L | 5 | 0.05 | 46 |
| BHC3003-5-0.06L | 0.06 | 54 |
| BHC3003-5-0.08L | 0.08 | 72 |
| BHC3003-5-0.1L | 0.1 | 91 |
| Alloy | Al3003 and Al5052 |
| Supply form | Unexpanded (block, strip) or expanded(slice) |
| Unperforated |
3. Micro- Porous aluminium core has several advantages:
• Competitive Advantage
• Light weight
• High strength
• Super flatness
• Compression, shear and corrosion resistance
• Flatness
4. Applications:
• Building materials industry
• Lighting industry
• Industry
• Ship and so on
5. Micro-porous aluminum honeycomb core of more pictures:
6. History
1957 Besin (Dutch) International Group was established and dedicated to research and development of BEECORE and BEEBOARD.
1958 Besin brought honeycomb technology into China, and Besin (Suzhou) company was established.
2002 Beecore (Guangdong) factory was established and have 10 aluminum honeycomb production lines.
2009 Suzhou Beecore Honeycomb Materials Co., Ltd was established and mainly produce aluminum honeycomb core and paper honeycomb core and other products.
2010 Beecore products are widely used for railway industry, Shanghai Expo, marine furniture etc.
2014 Beecore developed micro-porous aluminum honeycomb core and slant-porous aluminum honeycomb core, as well as honeycomb filters.
2015 Beecore added honeycomb panels production lines, specialized in super length, width, curved, and special honeycomb panels of industry field.
2016 The self-developed aluminum honeycomb equipment has been exported to Europe, America, Asia and already obtained the technology patent in China.
2017- so far Suzhou Beecore Honeycomb Materials Co., Ltd is honored as the high-technology innovation enterprise.
7. Factory show- manufacturing process of aluminum honeycomb core
8. Exhibition
9.Company certificate
10. Aluminum honeycomb core package
11. FAQ
Q1. What are the advantages of aluminum honeycomb core?
A: Aluminum honeycomb core has the advantages of light weight-high strength, high surface flatness, environmental protection and no pollution.
Q2. What is the packaging method of aluminum honeycomb core?
A: Aluminum honeycomb core of samples are packed in cardboard and bulk orders are packed in plywood cases.
12. Why choose us?
